Description
– Power – 3,5 kw
– Managament – PLC Control
– One Appointments Units
– Run out table – 15 m ( Possibility of upgrade )
– Diameter of block – 300mm
– Wire diameter range – 1.8 – 3.2 mm – 1550 N/mm2
– Ring diameter – 300 – 420 mm - possible another diameter of rings
– Capacity – 52,5 m2/8h for mesh with next characteristics :
Ring diameter 350 mm – 9 coils
Wire diameter – 3 mm
Mesh dimensions – 10 x 5 m
– dimensions of mesh – 10x 5 m ( possibly longer ) depends on the weight of the final mesh
– Power – 3,5 kw ( complete line )
– Number of workers – 1 per shift
– Managament – PLC Control
– One Appointments Units
– Run out table – 15 m ( Possibility of upgrade )
– Diameter of block – 300mm
– Wire diameter range – 1.8 – 3.2 mm – 1550 N/mm2
– Ring diameter – 300 – 420 mm - possible another diameter of rings
– Capacity – 52,5 m2/8h for mesh with next characteristics :
Ring diameter 350 mm – 9 coils
Wire diameter – 3 mm
Mesh dimensions – 10 x 5 m
– dimensions of mesh – 10x 5 m ( possibly longer ) depends on the weight of the final mesh
– Power – 3,5 kw ( complete line )
– Number of workers – 1 per shift
